Builder: Hans Christian
Type of Rig: Cutter
Year Built: 1984
LOA: 41'
LWL: 29'2"
Beam: 11'8"
Draft: 6'
Displacement: 18,500 lbs.
Ballast: 6,800 lbs. (Iron)
Hull Material: Fiberglass
Deck Material: Teak
Designer: Harwood S. Ives/Scott SpragueEngine:
-Yanmar 3QM30 30HP Diesel
-Oil-Pressure/water-temp/tach gauges, hour meter
-Racor fuel filter + Yanmar fuel filter
-120 Amp Balmar alternator
Electrical:
-6x Dyno GC6b 6-Volt batteries (total 735AH) in 2 banks wired in series for 12 volts installed Fall 1999
-Heart Interface Freedom 10 charger/inverter
-Link-10 battery monitor - new Summer 2000
-30 amp shore power
-Wired for telephone and cable
-Air-403 Marine wind generator (400 Watt at 26kts) - new Spring 2000
-Uni-Solar USF32 flexible solar panel (32 Watt in direct sunlight) - new Summer 2000
Tank Capacities:
-Water = 93 USG (2x45 gallon tanks in keel and 3 gallon hot water tank)
-Diesel = 80 USG (in keel)
-Propane = 3 USG (in sealed cockpit locker)
-Waste = 10 USG (in keel)
Ground Tackle:
-Lofrans Tigres 1000-Watt automatic windlass
-45lb CQR (bow)
-30lb Bruce (bow) - new Spring 2000
-25lb Danforth (stern)
-210 Feet 3/8inch diameter BBB Chain (bow) - new Spring 2000
-400 Feet 5/8inch rode at end of chain (bow)
-25 Feet 5/16inch chain (stern)
-200 Feet 1/2inch rode at end of chain (stern)
Galley/Plumbing:
-GSI 2-burner LPG stove with oven
-Auto propane shut-off valve near stove
-ShurFlow Silencer pressure pump - new Winter 2001
-ShurFlow accumulator tank for even water pressure - new Winter 2001
-Marble counter-top
-Bronze faucet for pressurized hot and cold water
-Fresh and salt water “Gusher” foot pumps
-Electric/automatic bilge pump, sump pump (Rule)
-Manual bilge pump (Henderson)
-Shore-power/engine-heated hot water
-Adler-Barber Cold-Machine refrigerator/freezer
-Power-Survivor 30 water maker
-Magma propane BBQ
Head:
-Standing shower/wet-locker with auto sump pump
-Marble counter-top
-Stainless sink with bronze hot and cold water faucet
-Raritan PH-II manual head with Y-valve to holding tank
Lighting:
-Red & white lighting throughout
-Halogen reading lamps in berths and in salon
-Alpenglow fluorescent red/white light above salon table
-Red floor lighting
-Masthead Tri-Color light - new Winter 2000
-Mast “steaming” light
-Deck lights
-Bow and stern running lights
-Compass light/instrument lights
-Plug-in “Guest” spot lightHeating:
-Sigmar diesel furnace
-Engine-driven heater
Safety Equipment:
-Avon 6-Person life raft (professionally repacked Spring 2000)
-4 Fire extinguishers (1 Halon in galley, 1 Auto-Halon above engine) re-charged 1999
-4 life vests
-1 Life Sling
-Numerous flares, 2 flare guns
-All through-hulls have emergency plugs tethered beside
Sailing Equipment/Canvas:
-6x Maxwell 2-speed self-tailing, 2 Maxwell single-speed winches (all rebuilt Summer 2000)
-85% Yankee headsail (338 sq. ft.) - new Spring 2001
-Full batten main (281 sq. ft.) with Lazy-Jacks and boom gallows (1-10 scale this is an 7)
-Staysail (169 sq. ft.) (1-10 scale this is a 8)
-Storm Jib (1-10 scale this is a 10)
-Rigging: 3/8" and 5/16" 1x19 stainless wire
-Full boat cover
Steering:
-Pedestal cable/quadrant steering system re-built Spring 2000
-Monitor wind vane self-steering
-AutoHelm 3000 electronic steering
Electronics/Communications/Navigation:
-Richie Globemaster pedestal compass
-Silva hand-held compass
-Furuno Model 1621 8-mile radar
-Garmin Model 128 GPS
-AutoHelm 3000
-Icom IC-735 HF HAM Transceiver with AH-2 Automatic antenna tuner (converted for SSB use)
-Insulated backstay antenna
-Standard Horizon II VHF Radio
-Datamarine Corinthian Series depth sounder/knot log/wind instrumentation
-Panasonic CD Player with AM/FM radio and Bose speaker system
Recent Major Improvements/Maintenance:
-Haul-out Spring 2001 (painted bottom with Woolsey Neptune anti-fouling and replaced zincs)
-Haul-out Spring 2000 (painted bottom with Woolsey Neptune anti-fouling, replaced zincs, replaced cutlass bearing, replaced propeller shaft and coupler, re-built steering system with new bearings, cable, and chain.)
-Re-mounted battery boxes in lazaret Summer 2000
-Re-cabled battery system with installation of E-meter Summer 2000
-New custom innerspring mattress from Handcraft Mattress Co. - Fall 2000
